C series

Time:2015-12-16 | Read:731 | Posted: Site Editor
C10

The Size (W * D * H) : 302 * 298 * 500 mm
System: 1 * 10 inch binary frequency speakers
Frequency response: 65 hz - 18 KHZ (3 db)
Continuous 1000 w power: 250 w peak
Nominal resistance: 8 ¦¸
Sensitivity: 97 db / 1 w / 1 m
The maximum sound pressure: 123 db continuous peak 129 db
Cover Angle: horizontal vertical 50 ¡ã 80 ¡ã
High unit: imported units, 1 inch, throat and mouth 44 mm voice coil
The bass unit: custom-made quality unit, 50 mm voice coil
Hanging point: 16 M8 screw hanging point
Connectors: NLV4MP
Support: the base support 35 mm hole
Handle: wooden one
Body material: CNC manufacturing, high density poplar plywood
Waterproof paint processing: the wear-resisting of compound
15 kg weight:
X290x500mm size (WxDxH) : 300


C12

System: 1 * 12 inches of binary frequency speakers
Frequency response: 55 hz - 19 KHZ (3 db)
Continuous 1600 w power: 400 w peak
Nominal resistance: 8 ¦¸
Sensitivity: 98 db / 1 w / 1 m
The maximum sound pressure: 124 db continuous peak 130 db
Cover Angle: horizontal vertical 50 ¡ã 80 ¡ã
High unit: imported units, inches, throat and mouth 44 mm voice coil
The bass unit: custom-made quality unit, 75 mm voice coil
Hanging point: 16 M8 screw hanging point
Connectors: NLV4MP
Support: the base support 35 mm hole
Handle: wooden one
Body material: CNC manufacturing, high density poplar plywood
Waterproof paint processing: the wear-resisting of compound
Weight: 20 kg
Size (W * D * H) : 366 * 390 * 630 mm


C15
System: 1 * 15 "binary frequency speakers
Frequency response: 52 hz - 19 KHZ (3 db)
Continuous 1600 w power: 450 w peak
Nominal resistance: 8 ¦¸
Sensitivity: 99 db / 1 w / 1 m
The maximum sound pressure: 125 db continuous peak 131 db
Cover Angle: horizontal vertical 50 ¡ã 80 ¡ã
High unit: imported units, 1.5 inches, throat and mouth 75 mm voice coil
The bass unit: custom-made quality unit, 75 mm voice coil
Hanging point: 12 M8 screw hanging point
Connectors: NLV4MP
Support: the base support 35 mm hole
Handle: wooden 2
Body material: CNC manufacturing, high density poplar plywood
Waterproof paint processing: the wear-resisting of compound
Weight: 35 kg
Size (W * D * H) : 430 * 455 * 690 mm
